Xerox® Versant® 280 Press

The Xerox Versant 280 Press is a powerful mid-production printing press suitable for small, busy print shops and enterprise environments. It can comfortably handle 80,000 prints per month, with a maximum monthly duty cycle of 750,000 pages. The Versant 280 Press is the successor to the popular Xerox Versant 80 machine.

Categories: ,

Description

PERFORMANCE

Rated speed:
80 ppm (8.5″ x 11″/A4), 52–350 g/m² with Performance Package
80 ppm (8.5″ x 11″/A4), 52-220 g/m²
60 ppm (8.5″ x 11″/A4), 221-350 g/m²
44 ppm (11″ x 17″/A3), 52–350 g/m² with Performance Package
44 ppm (11″ x 17″/A3), 52-220 g/m²
32 ppm (11″ x 17″/A3), 221-350 g/m²

Resolution:
– 2400 x 2400 dpi VCSEL ROS for sharpness, detailed shadows, and bright highlights
– 1200 x 1200 x 10 RIP rendering without down sampling for Ultra HD performance

Recommended average monthly volume:
80,000 pages per month

Duty cycle: 750,000 pages per month
Line Screens:
Halftone Screens for smoother, crisper resolution and improved gradients
– 150, 175, 200, 300, 600 Clustered Dot
– 150, 200 Rotated Line Screen
– FM Stochastic Screen

CAPABLITIES

Configurations:
Xerox® Versant® 280 Press
Xerox® Versant® 280 Press with Performance Package

Standard Capabilities: Color printing, copying, and scanning
Optional Capabilities: High-capacity feeding, stacking, and finishing
Printed Sides: Duplex
MICR: No

Other Scanning Features
E-Mail: Scan documents to email addresses as attachments to the emails
Network Scanning: Scan documents to the print server for further routing to up to four locations: a mailbox on the server, an email address, a network shared folder, and/or an ftp site
Scan to PC: Scan documents to a Windows® PC
Store to USB: Scan documents to a flash drive plugged into the USB port
Store to Folder: Scan documents to a folder on the press for storage

TECHNOLOGY

Color Technology: Automated Color Quality Suite

PAPER HANDLING

Paper sources: 3 standard trays plus bypass; 3 optional high capacity feeders
Standard paper capacity: 1,900 sheets
Maximum paper capacity with options: 9,900 sheets
Media Dimensions – Minimum: 3.9″ x 5.7″ (98 mm x 146 mm)
Media Dimensions – Maximum: 13″ x 26″ (330 x 660 mm)
Media Weight – Minimum: 52 gsm
Media Weight – Maximum: 350 gsm

Media Types: Coated and uncoated papers, bright papers, labels, business cards, glossy brochures, window decals, durable/synthetic papers, greeting cards, tabs, embossed, polyesters and custom solutions
Mixed-stock jobs supported

Auto Duplex: High Capacity trays (52 – 300 g/m²)
Standard trays (52 – 256 g/m²)
Manual sheet inserter (52 – 300 g/m²)

INPUT

Tray 1: 550 sheets
Tray 2: 550 sheets
Tray 3: 550 sheets

High Capacity Feeder:
– High Capacity Feeder (HCF)
– One Tray Oversized High-Capacity Feeder (OHCF)
– Advanced Oversized High-Capacity Two Tray Feeder (Adv OHCF)

Optional High Capacity Feeder:
– High Capacity Feeder: One Tray 2,000 sheets, 8.5″ x 11″/A4, 64 – 220 g/m² – uncoated only
– Oversized High Capacity Feeder: 2,000 sheet capacity, min size with Tray Inserter 3.9″ x 5.8″ (100 x 148 mm), max size 13″ x 19.2″ (330 x 488 mm); 52 g/m² – 350 g/m² – uncoated and coated
– Advanced Oversized High Capcity Feeder: 4,000 sheet capacity, min size with Tray Inserter 3.9″ x 5.8″ (98 x 148 mm), max size 13″ x 19.2″ (330 x 488 mm); 52 g/m² – 350 g/m² – uncoated and coated

Standard Duplex Automatic Document Feeder:
– Single-pass Duplex Automatic Document Feeder, up to 200 ipm color / B&W, 250-sheet capacity, up to 11″ x 17″ (A3), 38 g/m² (16 lb. bond) to 200 g/m² (53 lb. bond), copy or scan to a variety of output options

Inserter: 250-sheet Xerox Inserter

PRINT CONTROLLERS

Digital Front Ends:
Xerox® EX 280 Print Server Powered by Fiery®
Xerox® EX-i 280 Print Server Powered by Fiery®
Xerox® FreeFlow® Print Server

ENVIRONMENTAL

Electrical Requirements:
North America: 208-240 V, 50/60 Hz, 16 amps/requires 20A circuit, NEMA 6-20-R socket
Europe: 220-240 V, 50 Hz, 20 amps/requires 20A circuit, PCE Shark 023-6 mating socket
Additional electrical required for print server and feeding/finishing devices:
115 VAC, 15 Amp for 60 Hz or 220 VAC, 10 Amp for 50 Hz (Western Hemisphere)
220-240 Volts, 10 Amp, 50 Hz (Europe)

Dimensions:
30″ (W) x 33″ (D) x 48″ (H)
760 mm (W) x 831 mm (D) x 1,212 mm (H)
Weight: 651 lb. (295 kg)

CERTIFICATIONS

Sustainability: EPEAT
